| Ball Diameter in MM |
Steel Ball Diameter in MM |
Steel Balls Diameter in INCHES |
Steel Balls Diameter in INCHES |
||
|---|---|---|---|---|---|
| 1.00 | 7.00 | Fraction | Decimal | Fraction | Decimal |
| 1.50 | 8.00 | 3/64" | 0.047" | 1/4" | 0.250" |
| 2.00 | 8.50 | 1/16" | 0.063" | 9/32" | 0.281" |
| 2.50 | 9.00 | 3/32" | 0.094" | 5/16" | 0.313" |
| 3.00 | 9.50 | 1/8" | 0.125" | 11/32" | 0.344" |
| 3.50 | 10.00 | 5/32" | 0.156" | 3/8" | 0.375" |
| 4.00 | 10.50 | 3/16" | 0.188" | 13/32" | 0.406" |
| 4.50 | 11.00 | 7/32" | 0.219" | 7/16" | 0.438" |
| 5.00 | 11.50 | 15/64" | 0.234" | 15/32" | 0.469" |
| 5.50 | 12.00 | . | . | 1/2" | 0.500" |
| 6.00 | 12.50 | . | . | . | . |
| Size | Nos / kg | Weight of 1000 balls in kg. |
Size | Nos / kg | Weight of 1000 balls in kg. |
|||
|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | |||||
| 3/32" | 2.381 | 18058 | 0.055 | 5/8" | 15.875 | 61 | 16.393 | |
| 2.500 | 15612 | 0.064 | 16.000 | 60.00 | 16.667 | |||
| 7/64" | 2.778 | 11478 | 0.087 | 21/32" | 16.669 | 53.00 | 18.868 | |
| 3.000 | 9035 | 0.111 | 17.000 | 50.00 | 20.000 | |||
| 1/8" | 3.175 | 7622 | 0.131 | 11/16" | 17.463 | 46.00 | 21.739 | |
| 3.500 | 5689 | 0.176 | 18.000 | 42.00 | 23.809 | |||
| 5/32" | 3.969 | 3902 | 0.256 | 23/32" | 18.256 | 40.00 | 25.000 | |
| 4.000 | 3811 | 0.262 | 3/4" | 19.050 | 35.00 | 28.571 | ||
| 4.500 | 2677 | 0.374 | ||||||
